Product Description
High-performance panel saw technology for demanding production
The HOMAG SAWTEQ S-500 is a high-performance industrial panel dividing saw designed for demanding applications, high material throughput and reliable series production.
Combining a robust machine construction with advanced HOMAG technology, the SAWTEQ S-500 delivers high cutting precision, productivity and long-term reliability. It is an ideal solution for furniture manufacturers, panel processors and woodworking businesses looking to increase production capacity while maintaining consistently high-quality results.
Available in a range of configurations, the SAWTEQ S-500 can also be integrated with automated panel storage and material handling systems, making it suitable for highly efficient production environments.
Contact us to enquire about this product
If you are interested in this product and wish for a customised quote, contact us at the number +44 (0) 28 8674 8863 or fill in the enquiry form below and we will be happy to provide you with more info!
Why choose HOMAG SAWTEQ S-500?
For manufacturers processing large volumes of wood-based panels, the SAWTEQ S-500 provides the combination of speed, precision, durability and automation capability needed for modern production.
Whether you are upgrading an existing panel saw, increasing production capacity or planning a fully automated material flow, the SAWTEQ S-500 can be configured around your requirements.
Key Benefits
- High-performance panel dividing saw for demanding production environments
- Robust construction designed for high material throughput
- Excellent cutting accuracy and repeatability
- Available with cutting lengths from 3,200 to 6,500 mm
- Saw carriage speeds of up to 130 m/min
- Program fence speed of up to 90 m/min
- Main saw motors available up to 54 kW
- Advanced CADmatic 5 control system
- 24″ Full HD multi-touch operating display
- Can be integrated with HOMAG panel storage and automation systems
- Designed for easy servicing and maintenance
- Available with customised configurations to suit individual production requirements
Built for precision and durability
The SAWTEQ S-500 features a solid machine construction and innovative guide systems designed to maintain precision throughout demanding production schedules.
Its SORB TECH saw body provides excellent vibration damping and sound absorption, helping to improve cutting quality while extending saw blade service life.
Compared with conventional steel supports, SORB TECH technology can provide:
- Up to 10 times better vibration damping
- Up to 20% higher sound absorption
- Up to 30% longer saw blade service life
This combination of stability, precision and durability makes the SAWTEQ S-500 particularly well suited to businesses where high productivity and consistent cutting quality are essential.
Designed for high-volume panel processing
With cutting lengths available from 3,200 to 6,500 mm and a saw carriage speed of up to 130 m/min, the SAWTEQ S-500 is engineered to keep production moving.
The machine can be configured to meet different production requirements and can be connected to automated storage systems to create a more streamlined material flow — from panel storage through to cutting and onward processing.
HOMAG CADmatic 5 control
The CADmatic 5 operating system provides intuitive machine control through a 24″ Full HD multi-touch display.
The user-friendly interface helps operators manage cutting programmes efficiently while maintaining precise and repeatable production.
Technical Specifications
| Specification | SAWTEQ S-500 |
|---|---|
| Saw blade projection | 150 mm / 170 mm optional |
| Cutting length | 3,200 / 3,800 / 4,300 / 5,600 / 6,500 mm |
| Program fence speed | Up to 90 m/min |
| Saw carriage speed | Up to 130 m/min / 150 m/min optional |
| Main saw motor | 30 kW / 47 kW optional at 50 Hz |
| Main saw motor | 35 kW / 54 kW optional at 60 Hz |
| Monitor | 24″ Full HD multi-touch |
| Operating software | CADmatic 5 |
Specifications and available configurations may vary. Please contact ETM for further information.
Talk to Electro-Tech Machinery
ETM can help you find the right HOMAG panel dividing saw for your production requirements. From standalone panel saws to integrated storage and automation solutions, our team can advise on the right equipment for your business.
Additional information
| Brand | Homag |
|---|---|
| Machine Category | New Machines |
| Machine Function | Woodworking |
| Machine Type | Beamsaw, Panelsaws |
